MOUNTING BRACKET 60x60x20 WITH DOWEL (B30-23)
商品描述
The mounting bracket and dowel are used in any application where the extrusions are subjected to torsion but must not twist. A safe extrusion connection. The brackets can be attached with A/B 35-20 T-bolts or using A/B 32-... threaded plates and screws.
Product selection
| Part Number | Description | B | ø | M |
|---|---|---|---|---|
| B30-23 | MOUNTING BRACKET 60x60x20 WITH DOWEL | 20 | 6,5 | M6 |
